SUNMAN eArc 430W FLEXIBLE SOLAR PANEL

SUNMAN eArc 430W FLEXIBLE SOLAR PANEL

SKU:eASMF430-12X12UW

Regular price $669.00
Regular price Sale price $669.00
Sale Sold out

Tax included. Shipping calculated at checkout.

Superior solar technology with the newly improved, compact Mono-PERC solar panels. These lightweight yet robust panels are perfect for various applications, including caravans, motorhomes, yachts, trains, and buses.

  • Lightweight and durable construction with cutting-edge technology
  • Highly efficient monocrystalline cells for optimal energy production
  • Flexible design for easy installation on various surfaces
  • Endorsed by the Clean Energy Finance Corporation and Australian Renewable Energy Agency
  • CEC-approved for residential and commercial use
  • 10-year product warranty for buildings and 5 years for mobile applications

430W
Solar cells 144 (12x12)
Maximum Power (Pmax) 430
Maximum Power Voltage (Vmp) 42.0
Maximum Power Current (Imp) 10.24
Open-circuit Voltage (Voc) 49.8
Short-circuit Current (Isc) 10.74
Operating Temperature (°C) -40 °C to 85 °C
Maximum System Voltage 1000 V DC (IEC)
Maximum Series Fuse Rating 20 A
Application Class Class A
Power Tolerance 0/+5 W
Backsheet White
Junction box IP 68 rated (each j-box has one by-pass diode)
Output Cables Photovoltaic technology cable 4.0 mm2, (+)150 / (-)450 mm
Connector MC4 compatible
