PREDATOR 12V 150AH SLIM DEEP CYCLE GEL BATTERY

🔋 PREDATOR FTG12-150 SLIM DEEP CYCLE GEL BATTERY – 12V 150AH

Slim 110mm Deep Cycle Gel Battery – 150Ah Rated Capacity, M8 Terminals, Lead-Calcium Grids & Maintenance-Free Construction

⚡ The Predator FTG12-150 is a high-capacity 12V deep cycle Gel battery specifically designed for installations where available width is limited but substantial auxiliary battery capacity is still required.

At only 110mm wide, the narrow FTG-series case provides a practical solution for compatible vehicle auxiliary-power, 4WD, RV, marine, UPS and standby-power installations where a conventional-width deep cycle battery may be difficult to accommodate.

The terminal design and location are intended to provide straightforward installation and access, while a unique one-way vent valve controls gassing and minimises water loss for true maintenance-free operation.

With a nominal 150Ah rating, M8 terminals, approximately 4.3mΩ internal resistance, lead-calcium alloy grids and excellent deep cycle characteristics, the FTG12-150 provides substantial 12V stored energy in a narrow-format battery case.

---

⚡ KEY FEATURES

🔋 12V 150Ah Deep Cycle Gel Battery
Provides a nominal 12V output with a supplied 150Ah rated capacity at the 10-hour rate.

📈 157.6Ah @ 20-Hour Rate
The manufacturer data lists a 20-hour rated capacity of 157.6Ah.

📏 Slim 110mm Wide Case
The narrow battery design is ideal for compatible installations where available width is limited.

🔄 Dedicated Deep Cycle Gel Technology
Designed for repeated discharge and recharge applications where dependable auxiliary or stored power is required.

🚙 Vehicle Auxiliary Power
The Predator FTG series is specifically designed as a solution for compatible vehicle auxiliary-power systems.

🧪 Lead-Calcium Alloy Grids
Lead-calcium alloy grid construction is designed to reduce corrosion and extend battery cycle life.

💧 Spill-Proof Design
Gel electrolyte construction provides a spill-resistant design suited to compatible mobile and auxiliary-power installations.

🚫 No Electrolyte Stratification
Gel construction eliminates the electrolyte stratification associated with conventional flooded battery designs.

🌡️ High Thermal Stability
Designed to provide stable performance across a broad operating-temperature range.

🛠️ Maintenance-Free Operation
A one-way vent valve controls gassing and minimises water loss, eliminating routine electrolyte maintenance.

📉 Low Self-Discharge
The supplied technical specification lists self-discharge at no more than 3% per month.

🔩 M8 Terminals
M8 terminals provide secure bolted electrical connections for compatible cable lugs.

⚡ Approx. 4.3mΩ Internal Resistance
The supplied technical specification lists approximately 4.3mΩ internal resistance.

---

📏 BUILT FOR NARROW INSTALLATION SPACES

One of the major advantages of the Predator FTG12-150 is its narrow 110mm case width.

With overall dimensions of approximately 551mm long × 110mm wide × 288mm high, the FTG12-150 is designed to provide substantial deep cycle capacity while occupying considerably less installation width than many conventional-format high-capacity batteries.

This narrow configuration can make the FTG12-150 particularly useful where a battery needs to be positioned beside equipment, within a custom battery compartment or in another restricted-width installation.

⚠️ IMPORTANT: The FTG12-150 is narrow but is also approximately 551mm long, 288mm high and 46.4kg. Always physically measure the installation location and confirm mounting strength before purchase.

---

🔋 TRUE DEEP CYCLE GEL CONSTRUCTION

The Predator FTG series is specifically designed for deep cycle applications.

Unlike a starting battery that is primarily designed to provide short bursts of high cranking current, the FTG12-150 is designed to provide stored energy over longer periods before being recharged.

This makes it suitable for compatible auxiliary electrical systems where appliances and equipment regularly draw power from the battery.

⚠️ IMPORTANT: Deep cycle construction does not mean the battery should routinely be discharged completely. Battery service life is strongly influenced by depth of discharge, charging quality, operating temperature and how promptly the battery is recharged after use.

---

🧪 GEL BATTERY TECHNOLOGY

The Predator FTG12-150 uses Gel battery technology rather than AGM construction.

The electrolyte is immobilised within the Gel battery design, helping provide spill-resistant operation and eliminating electrolyte stratification.

Gel technology also provides excellent deep cycle characteristics and high thermal stability for compatible auxiliary and stored-energy applications.

⚠️ IMPORTANT: GEL and AGM are both sealed lead-acid battery technologies, but their recommended charging voltages can differ. Use charging equipment suitable for GEL batteries and follow the FTG12-150 charging specifications.

---

🧱 LEAD-CALCIUM ALLOY GRIDS

The Predator FTG series uses lead-calcium alloy grids designed to reduce corrosion and support extended battery cycle life.

This construction contributes to the FTG12-150’s suitability for repeated deep cycle operation and long-term auxiliary-power applications.

---

💨 ONE-WAY VENT VALVE

The FTG-series battery design incorporates a unique one-way vent valve.

This valve is designed to control internal gassing and minimise water loss, helping provide true maintenance-free operation.

There is no routine requirement to check or top up electrolyte as with a conventional serviceable flooded lead-acid battery.

---

🔌 150AH RATED CAPACITY

Nominal voltage: 12V

Nominal product capacity: 150Ah

The manufacturer data lists the FTG12-150 as a 150Ah deep cycle Gel battery at the 10-hour rate.

The detailed specification also lists a 20-hour capacity of 157.6Ah, an 8-hour capacity of 144Ah and a 5-hour capacity of 131.5Ah.

Actual usable capacity and runtime will vary according to load, battery condition, operating temperature, system losses and discharge cutoff voltage.

---

📊 SUPPLIED CAPACITY RATINGS

The manufacturer data sheet lists:

20-hour rate: 157.6Ah at a supplied 5.27A to 1.8V per cell

10-hour rate: 150Ah at a supplied 10A to 1.8V per cell

8-hour rate: 144Ah at a supplied 11.9A to 1.8V per cell

5-hour rate: 131.5Ah at a supplied 17.3A to 1.75V per cell

⚠️ IMPORTANT: The discharge-current figures shown in the manufacturer data sheet do not arithmetically align with the stated Ah capacities and hour ratings. They have been reproduced here exactly as published. Confirm the current manufacturer specifications before using these figures for engineering, battery-bank sizing or precise runtime calculations.

---

⚡ APPROX. 4.3mΩ INTERNAL RESISTANCE

The supplied technical specification lists internal resistance at approximately 4.3mΩ.

Low internal resistance helps reduce internal electrical losses and supports efficient current delivery when the battery is operated within its intended specifications.

---

🔁 BULK / CYCLE CHARGING

Supplied bulk charge voltage:

14.1V–14.4V at 25°C

Maximum charge current:

37.5A

⚠️ IMPORTANT: The FTG12-150 is a GEL battery. Ensure the charger, DC-DC charger, solar regulator or other charging source is configured for the supplied GEL charging voltage. Do not automatically use an AGM charging profile unless its actual voltage settings are compatible with the battery specification.

---

🔄 STANDBY / FLOAT CHARGING

Supplied standby / float voltage:

13.5V–13.8V at 25°C

This voltage range applies when the FTG12-150 is used in a compatible standby application and remains connected to an appropriate regulated charging source.

---

🚙 VEHICLE AUXILIARY POWER

The Predator FTG12-150 is specifically designed for compatible vehicle auxiliary-power applications.

Its slim 110mm width can be particularly useful where conventional battery dimensions make installation difficult, while its 150Ah-class deep cycle capacity provides a substantial reserve of power for compatible 12V accessories.

Potential auxiliary loads can include compatible refrigeration, lighting, communications equipment and other 12V appliances where the system has been correctly designed around the battery’s capacity and charging requirements.

⚠️ IMPORTANT: Modern vehicle auxiliary installations generally require an appropriate charging system. Confirm that the vehicle-side DC-DC charger or charging equipment supports GEL battery charging within the FTG12-150 voltage and current requirements.

---

🚐 4WD & RV AUXILIARY POWER

4WD and RV auxiliary power is specifically listed among the intended applications for the Predator FTG12-150.

The combination of high deep cycle capacity and a narrow 110mm profile can be useful in compatible recreational electrical installations where width is restricted.

⚠️ IMPORTANT: At approximately 46.4kg, the FTG12-150 is a substantial battery. Vehicle payload, structural mounting strength and secure battery restraint must be considered before installation.

---

🚐 CARAVAN & CAMPER APPLICATIONS

The slim format and deep cycle characteristics of the FTG12-150 can make it suitable for compatible caravan, camper and recreational electrical installations.

Its 150Ah-class capacity provides substantial stored energy for appropriately sized 12V appliances and accessories.

Actual suitability depends on daily electrical consumption, charging availability, allowable depth of discharge and required battery runtime.

---

🚤 MARINE APPLICATIONS

Marine use is included among the manufacturer-listed applications for the FTG12-150.

The battery may suit compatible marine auxiliary or house-power systems where its physical dimensions, capacity, charging characteristics and mounting requirements can be accommodated.

⚠️ IMPORTANT: Marine installations require appropriate structural support, secure battery restraint, protected electrical connections and installation suitable for the vessel and operating environment.

---

☀️ SOLAR CHARGING APPLICATIONS

The FTG12-150 can be used with a compatible solar charging system where the regulator supports GEL battery charging.

The charging system should be configured within the supplied bulk-charge range of 14.1V–14.4V at 25°C and remain within the supplied maximum charge-current limit of 37.5A.

⚠️ IMPORTANT: Check the solar regulator’s actual GEL charging profile rather than relying only on a generic “lead acid” setting.

---

⚡ UPS & STANDBY POWER

UPS and standby-power systems are specifically listed among the intended applications for the FTG12-150.

Its 13.5V–13.8V standby / float voltage specification allows it to be maintained by compatible regulated standby charging equipment.

Always confirm the voltage, capacity, physical dimensions, terminal configuration and charging requirements specified by the UPS or standby-power equipment manufacturer.

---

⚡ INVERTER APPLICATIONS

The FTG12-150 may be used with a compatible inverter where the battery capacity, inverter power, cabling and circuit protection are appropriately designed.

High-power 240V appliances can result in substantial current draw from a 12V battery, so battery capacity alone should not be used to determine inverter suitability.

⚠️ IMPORTANT: Consider inverter continuous power, surge requirements, DC current, cable length, voltage drop, fuse or circuit-breaker rating and allowable battery depth of discharge when designing an inverter system.

---

📉 LOW SELF-DISCHARGE

Supplied self-discharge:

≤3% per month

The low self-discharge characteristic helps the FTG12-150 retain charge during periods when the battery is not actively being used.

Storage temperature, battery condition and initial state of charge can affect actual capacity retention.

---

🌡️ OPERATING & STORAGE TEMPERATURE

Discharge temperature: -20°C to +55°C

Charge temperature: 0°C to +40°C

Storage temperature: -20°C to +50°C

⚠️ IMPORTANT: Battery capacity, charge acceptance and service life are affected by temperature. Operate, charge and store the FTG12-150 within the supplied temperature ranges.

---

🔩 M8 TERMINALS

The FTG12-150 is supplied with M8 battery terminals.

These allow compatible ring terminals or cable lugs to be securely bolted to the battery.

⚠️ IMPORTANT: Use correctly sized cable, lugs, circuit protection and terminal hardware for the expected electrical load. Ensure connections are correctly tightened and protected against accidental short circuit.

---

🔧 SUITABLE APPLICATIONS

• 🚙 Compatible vehicle auxiliary-power systems
• 🚗 Passenger vehicle auxiliary applications
• 🚚 Truck and bus auxiliary applications
• 🚐 4WD and RV auxiliary power
• 🚐 Caravans and campers
• 🚤 Marine applications
• 🏕️ Camping power systems
• ☀️ Compatible solar-storage systems
• ❄️ Compatible 12V refrigeration systems
• 💡 Auxiliary lighting
• 📡 Communications equipment
• ⚡ UPS systems
• 🔋 Standby-power systems
• 🔌 Compatible inverter systems
• 🔋 Other compatible 12V deep cycle applications

---

📏 DIMENSIONS & WEIGHT

Length: 551 ±2mm

Width: 110 ±2mm

Height: 288 ±2mm

Nominal weight: Approximately 46.4kg

Case material: ABS

Terminal type: M8

---

📋 TECHNICAL SPECIFICATIONS

Brand / Range: Predator FTG Series

Model: FTG12-150

Battery type: Deep Cycle GEL

Nominal voltage: 12V

Nominal product capacity: 150Ah

20-hour capacity: 157.6Ah

20-hour discharge specification: Supplied as 5.27A to 1.8V per cell

10-hour capacity: 150Ah

10-hour discharge specification: Supplied as 10A to 1.8V per cell

8-hour capacity: 144Ah

8-hour discharge specification: Supplied as 11.9A to 1.8V per cell

5-hour capacity: 131.5Ah

5-hour discharge specification: Supplied as 17.3A to 1.75V per cell

Internal resistance: Approximately 4.3mΩ

Length: 551 ±2mm

Width: 110 ±2mm

Height: 288 ±2mm

Nominal weight: Approximately 46.4kg

Terminal: M8

Case material: ABS

Discharge temperature range: -20°C to +55°C

Charge temperature range: 0°C to +40°C

Storage temperature range: -20°C to +50°C

Maximum charge current: 37.5A

Bulk charge voltage: 14.1V–14.4V at 25°C

Standby / float voltage: 13.5V–13.8V at 25°C

Self-discharge: ≤3% per month

Grid construction: Lead-Calcium alloy according to supplied product information

Maintenance: Maintenance free

⚠️ TECHNICAL DATA NOTE: The discharge currents published alongside the manufacturer’s 20-hour, 10-hour, 8-hour and 5-hour Ah capacities appear internally inconsistent with those stated hour rates. The published figures have not been silently corrected in this listing. Confirm the current manufacturer data before precise electrical calculations.

---

⚠️ INSTALLATION & COMPATIBILITY CHECKLIST

Before purchasing the Predator FTG12-150, confirm that the battery matches the electrical, physical and charging requirements of your application.

• 12V system compatibility
• Required 150Ah-class deep cycle capacity
• 551mm battery length
• 110mm narrow case width
• 288mm battery height
• Approximately 46.4kg battery weight
• Available installation space
• Suitable battery restraint and structural support
• M8 terminal compatibility
• Correct terminal polarity and cable routing
• Correct cable size for the expected load
• Correct fuse or circuit-breaker protection
• GEL-compatible charging system
• 14.1V–14.4V bulk-charge compatibility
• 13.5V–13.8V float-charge compatibility
• 37.5A maximum charge-current requirement
• Required electrical load and runtime
• Vehicle payload and mounting requirements where applicable

⚠️ IMPORTANT: This is a GEL battery, not an AGM battery. Confirm that all charging equipment is suitable for GEL chemistry and the supplied charging voltages.

⚠️ IMPORTANT: At approximately 46.4kg, the FTG12-150 requires a strong mounting structure and secure battery restraint suitable for the installation.

⚠️ IMPORTANT: The 110mm slim width does not mean the battery will fit every slimline location. The battery is approximately 551mm long and 288mm high, so all three dimensions must be checked.

⚠️ IMPORTANT: Do not select a replacement battery based on voltage and Ah rating alone. Confirm dimensions, terminals, polarity, charger compatibility, required capacity and available installation space.

---

❓ FREQUENTLY ASKED QUESTIONS

What is the Predator FTG12-150?

The FTG12-150 is a 12V slim deep cycle Gel battery designed for compatible auxiliary-power, recreational and stored-energy applications where installation width is limited.

Is the FTG12-150 a 150Ah battery?

Yes. The manufacturer identifies it as a 150Ah battery at the 10-hour rating. The supplied data also lists a 20-hour capacity of 157.6Ah.

What is the 20-hour capacity?

The supplied manufacturer specification lists a 20-hour capacity of 157.6Ah.

What is the 10-hour capacity?

The supplied manufacturer specification lists a 10-hour capacity of 150Ah.

What is the 8-hour capacity?

The supplied manufacturer specification lists an 8-hour capacity of 144Ah.

What is the 5-hour capacity?

The supplied manufacturer specification lists a 5-hour capacity of 131.5Ah.

Are the published discharge-current figures correct?

The manufacturer data sheet publishes specific discharge currents alongside each capacity rating, but those currents do not arithmetically align with the stated Ah capacities and hour ratings. They have been reproduced as supplied rather than silently corrected. Confirm the latest manufacturer specification before precise runtime or engineering calculations.

Is this an AGM battery?

No. The Predator FTG12-150 is a Gel deep cycle battery. GEL and AGM batteries use different electrolyte designs and can require different charging settings.

Is it a deep cycle battery?

Yes. The Predator FTG series is specifically designed for deep cycle applications.

How wide is the battery?

The FTG12-150 is approximately 110mm wide, making its narrow profile one of the key advantages of the design.

What are the complete dimensions?

The supplied overall dimensions are 551 ±2mm long × 110 ±2mm wide × 288 ±2mm high.

How much does the FTG12-150 weigh?

The supplied nominal weight is approximately 46.4kg.

What terminals does it use?

The FTG12-150 uses M8 terminals.

What is the maximum charging current?

The supplied maximum charge current is 37.5A.

What bulk charging voltage should be used?

The supplied bulk charge voltage is 14.1V to 14.4V at 25°C.

What float voltage should be used?

The supplied standby / float voltage is 13.5V to 13.8V at 25°C.

Can I use an AGM charger?

Only if the charger’s actual voltage profile is compatible with the FTG12-150 Gel specification. A dedicated GEL mode is preferable where available. Confirm that the bulk voltage remains within 14.1V–14.4V at 25°C.

Can it be charged from a DC-DC charger?

Yes, provided the DC-DC charger supports GEL batteries and can be configured within the FTG12-150 charging requirements, including the supplied maximum charge current.

Can I use a 40A DC-DC charger?

The supplied maximum charge-current specification is 37.5A. A charger capable of 40A should only be used if its output can be limited to remain within the battery manufacturer’s maximum charge-current requirement.

Can it be charged from solar?

Yes, provided the solar regulator supports GEL charging and is configured within the supplied bulk and float voltage ranges.

Can it be used as a 4WD auxiliary battery?

Yes, 4WD and RV auxiliary power is specifically included among the manufacturer-listed applications. Confirm the 551 × 110 × 288mm dimensions, 46.4kg weight, mounting structure and GEL-compatible charging system before installation.

Can it be installed behind a seat?

The 110mm narrow case may help in restricted-width installations, but the FTG12-150 is approximately 551mm long, 288mm high and weighs 46.4kg. The actual vehicle space and mounting structure must therefore be measured and assessed before installation.

Can it be used in a caravan or camper?

Potentially. Its deep cycle construction and narrow format can suit compatible caravan and camper installations where the dimensions, battery weight, charging system and required capacity are appropriate.

Can it be used in a marine application?

Yes. Marine is included among the manufacturer-listed applications, subject to correct electrical compatibility, secure restraint and appropriate installation.

Can it run a 12V fridge?

Yes, in an appropriately designed 12V system. Actual fridge runtime will depend on average fridge consumption, ambient temperature, compressor duty cycle, battery condition and permitted depth of discharge.

Can it run lights and other camping accessories?

Potentially. The FTG12-150 provides substantial stored energy for compatible 12V loads, but total runtime depends on combined electrical consumption and how deeply the battery is discharged.

Can it run an inverter?

Potentially, provided the inverter load, battery cables, circuit protection and required runtime are appropriate. Higher inverter loads can draw substantial DC current and reduce available lead-acid battery capacity.

Can it be used for a UPS?

Yes. UPS is included among the manufacturer-listed applications. Confirm the UPS requires a compatible 12V GEL battery and that its charging settings match the FTG12-150 specifications.

Can it be used for standby power?

Yes. Standby power is specifically listed as an application, with a supplied standby / float voltage of 13.5V–13.8V at 25°C.

Is it spill proof?

The supplied product information describes the Predator FTG series as having a spill-proof Gel design.

Does it require water to be added?

No. The FTG12-150 is designed as a maintenance-free battery and does not require routine electrolyte topping-up.

What is the self-discharge rate?

The supplied specification lists self-discharge at no more than 3% per month.

What is the internal resistance?

The supplied internal resistance is approximately 4.3mΩ.

What is the discharge temperature range?

The supplied discharge temperature range is -20°C to +55°C.

What is the charging temperature range?

The supplied charging temperature range is 0°C to +40°C.

What is the storage temperature range?

The supplied storage temperature range is -20°C to +50°C.

Can I replace another 12V 150Ah battery with the FTG12-150?

Potentially, but voltage and capacity alone do not confirm compatibility. Check the 551 × 110 × 288mm dimensions, M8 terminal configuration, polarity, 46.4kg weight and GEL charging requirements before installation.

What should I check before ordering?

Confirm the 12V system voltage, required capacity, 551mm length, 110mm width, 288mm height, 46.4kg weight, M8 terminals, GEL-compatible charging system, expected electrical load and available mounting space before purchase.

---

🔋 150AH DEEP CYCLE POWER IN A SLIM 110MM GEL BATTERY

Choose the Predator FTG12-150 when you need substantial 12V deep cycle capacity but conventional battery width is a problem.

With its narrow 110mm case, 150Ah nominal capacity, M8 terminals, lead-calcium alloy grids, maintenance-free Gel construction, low self-discharge and excellent deep cycle characteristics, the FTG12-150 provides a practical high-capacity solution for compatible vehicle auxiliary, 4WD, RV, marine, UPS and standby-power installations.

Confirm the available space, battery restraint, 46.4kg weight, M8 terminal configuration and GEL charging requirements before installation to ensure the Predator FTG12-150 is correct for your system.
