PREDATOR 100A 80A BMS DC-DC PACKAGE
PREDATOR 100A 80A BMS DC-DC PACKAGE
SKU:PP100-IDC25L
Couldn't load pickup availability
MANUALS & APPS
MANUALS & APPS
Included in this package
- Predator 100AH 80a BMS Slim LiFePO4 Battery
- Projecta ICD25L DC-DC Charger
- Redarc BCDC Core25 DC-DC Charger
- Redarc BCDC Core40 DC-DC Charger
- Redarc BCDC Alpha25 DC-DC Charger
- Redarc BCDC Alpha50 DC-DC Charger
- Thumper Control Box With Cig, USB & Anderson
- DC-DC Mounting Bracket
- 13.5mm (6B&S) Twin Core Cable
- 8mm (8B&S) Twin Core Cable
- 6mm (11B&S) Twin Core Cable
- 40A Midi Fuse
- 60A Midi Fuse
- 80A Midi Fuse
- 125A Midi Fuse
- Midi Fuse Holder
- Twin Midi Fuse Holder
- All Cable Lugs & Materials required For DIY Installation
The Predator Lithium range has been developed for those needing a high-quality power solution for their leisure, industrial or solar applications. These are suited for deep cycle applications where high cycle life and low weight is required. These batteries are only 70mm thick so are perfect for applications with limited space, such as slotting in behind the rear seats of popular twin cab utes. Slim, lightweight and sturdy these Slimline batteries are the premium auxiliary power companion for tradies, travellers and campers.
These 12V deep cycle batteries are packed with several features making them a serious contender in the growing lithium battery space. Among the different types of lithium battery chemistries available in the market, LiFePO4 batteries such as Predator Lithium are well regarded for safety and stability.
Predator Lithium Features
-
Longer Life
Over 3500 cycles at 80% Depth of Discharge - Fast RechargeThe Higher charge acceptance of LiFePO4 technology allows for safe and efficient recharging
- LightweightPredator Lithium batteries are around 60% lighter than equivalent AGM batteries
- Integrated Battery Management SystemThe Integrated BMS ensures the Predator LiFePO4 Batteries are safe and stable
- Bluetooth AppDownload the app to check real time battery information such as battery status, voltage, State of Charge (SoC), temperature and individual cell voltage.
- Greater Usable CapacityCompared to lead acid batteries which can only discharge to 50%, Predator lithium can be discharged using its full capacity
| Nominal Capacity | 200Ah |
| Nominal Energy | 2560Wh |
| Nominal Voltage | 12.8V |
| Charging Voltage | 14.4 ±0.2V |
| Float Charge Voltage (for stand-by use) | 13.6V |
| Maximum charge current | 150A |
| Recommended charge current | ≤ 100A |
| Maximum discharge current | 150A Constant |
| Discharge cut-off voltage | 11.2V |
| Dimensions (L x W x H), ±2mm | 600mm x 500mm x 70mm |
| Nominal Weight | 25kg |
| Bluetooth Connectivity | Yes, via App |
| Nominal Capacity | 100Ah |
| Nominal Energy | 1280Wh |
| Nominal Voltage | 12.8V |
| Charging Voltage | 14.4 ±0.2V |
| Float Charge Voltage (for stand-by use) | 13.6V |
| Maximum charge current | 80A |
| Recommended charge current | ≤ 50A |
| Maximum discharge current | 80A Constant |
| Discharge cut-off voltage | 11.2V |
| Dimensions (L x W x H), ±2mm | 560mm x 250mm x 70mm |
| Nominal Weight | 14kg |
| Bluetooth Connectivity | Yes, via App |
PROJECTA 25A INTELLI-CHARGE LITHIUM DUAL BATTERY CHARGER
An advanced DC/solar battery charger engineered for todays sophisticated lithium iron phosphate batteries.
The IDC25L DC-DC charger is purposely designed for charging auxiliary batteries.
It includes all the features needed to maintain the auxiliary battery to its optimum condition and to prolong the battery life.
SWITCHMODE TECHNOLOGY
The IDC25L converts your vehicle’s 12VDC/24VDC alternator power to the voltage level allowing your batteries to be fully charged, prolonging battery life and reliability. With the latest synchronous switching technology, efficiency of IDC25L exceeds 94% at typical full load condition.
DUAL INPUT OPERATION
Allows two energy sources to power the IDC25L simultaneously. Solar input takes precedence if solar and alternator inputs are present. When solar input cannot provide enough energy to the load, the IDC25L will draw power from solar and alternator simultaneously.
SOLAR MPPT
The IDC25L utilises sophisticated MPPT (Maximum Power Point Tracking) solar regulator technology. MPPT maximises the power generated from the solar panels to the auxiliary battery.
IGNITION CONNECTION
The ignition connection activates the lower input voltage operation to suit vehicles with smart (variable voltage) alternators.
| Operating Conditions |
| Alternator Input Voltage | 9–32Vdc |
| Maximum Solar Input Voltage | 28Vdc |
| Maximum Input Current | 40A |
| Input Current (No Load) | 20mA |
| Back Drain on Auxiliary Battery | 9.5 – 10.5mA |
| External LED Output – Constant Current | 4 mA |
| Output Current |
Input 9–11Vdc: 20A Input 11V–32dc: 25A |
| Input Fuse Rating |
40A |
| Output Fuse Rating |
40A |
| Maximum Output Power |
362.5W |
| Solar Input Turn On Voltage |
9V |
| Size |
149 x 122 x 42 mm |
| Weight |
800g |
| Charge Mode |
| Charge Type | 5 Stage |
|
Soft Start 1 Soft Start 2 |
Constant 1.25A if 2V< Auxiliary Battery Voltage <8V Constant 6.25A if 8V< Auxiliary Battery Voltage <10V |
|
Bulk |
*20A at 9-11Vdc, 25A at 11-32Vdc *Constant Current up to: 14.5V |
|
Absorption |
Constant Voltage until current drop to 2.5A 14.5V |
|
Float |
Keep Constant Voltage at 13.5V |
| Power Supply Mode |
| Output | Constant 13.8V (current limited to 25A) |
| Battery Range |
| Battery Capacity | 75–300Ah |
| Type of Batteries Supported | Lithium Iron Phosphate (LiFePO4) |
| Operating Mode |
| 12V Vehicle | 24V Vehicle |
| VSR Mode – Default (Ignition Override Not Connected) |
Turn on 13.4-20V |
Turn off <12.8V |
Turn on 26.8-32V |
Turn off < 25.6V |
| Low Voltage Mode – Ignition Override cable connected to ignition switch (ignition on) |
Turn on 12.2-20V |
Turn off <11.9V |
Turn on 24.4-32V |
Turn off <24V |
| Standards |
| EMC | C-Tick, AS/NZS CISPR11:2011 Class B |
| IP Rating | IP67 |
REDARC BCDC CORE25 DC BATTERY CHARGER
REDARC's BCDC Core 25A DC to DC In-Cabin Battery Charger is the next evolution of the legendary BCDC platform that has been powering off-grid adventures for over 10 years.
The BCDC Core is the perfect DC to DC charging solution for in-cabin, canopy, or battery box setups where dust and weatherproofing isn’t required. Each BCDC Core features REDARC’s tried and tested dual input DC charging tech plus an MPPT solar regulator and Green Power Priority™ all in the familiar and compact BCDC form factor. These features allow the BCDC Core to efficiently charge from both the alternator and solar simultaneously, ensuring maximum charge capacity no matter the situation.
Features
- Suitable for in-cabin and canopy installations only
- Compact form factor
- Simultaneous DC and solar charging with Green Power Priority™
- Maximises the performance and life of your auxiliary battery
- Suits 12V/24V standard and variable voltage/smart alternators
- Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries
- Suitable for use on vehicles with conventional alternator charging systems
Max Charge Efficiency
The BCDC Core features a Maximum Power Point Tracking (MPPT) solar regulator and 'Green Power Priority™'. With these features the BCDC Core will charge from both solar and the alternator simultaneously, maximising its charge rate and minimising the load on your alternator, saving fuel.
Compact & Silent
With no loud fans or relays and a small form factor, the BCDC Core can be tucked away, leaving room in the cabin for more important things. Don't ruin the look of your interior with bulky electronics. Hide it under the rear floor, behind a side panel or under the seats and make your power set up look like it was meant to be there.
Lithium Ready
With chemistry specific charging profiles, including lithium the BCDC Core ensures your batteries are ready for your next adventure. The award-winning technology in the BCDC Core has been independently verified and tested to ensure battery life is maximised, charging your battery to a proven 100%.*
For most applications, the BCDC Core 25A is suitable for battery bank sizes of 60-200AH for AGM and lead acid and up to 100AH for lithium. Check the manufacturer’s data for your battery and ensure that the ‘Continuous Current Rating’ of the charger does not exceed the manufacturer’s recommended maximum charging current. For higher capacity needs of over 200AH, REDARC recommends the BCDC Core 40A.
*Large capacity battery banks may require a few cycles to fully charge.
Backed by the Best
The BCDC Core is designed, tested and manufactured in Australia and is backed by our leading technical support and national REDNetwork certified installer network.
If you’re heading out into the bush and want to get there and back again safely – you can trust REDARC.
| Specifications |
| Battery Chemistry | Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only |
| Continuous Rating | 25A |
| Power Type - AC DC | DC TO DC |
| No Load Current | <100mA |
| Solar Input Voltage | 9 - 32V |
| Solar Switch On Voltage | 9V |
| Standby Current | <8mA |
| Operating Temperature | -15°C to 80°C |
| Weight | 900g |
| Height | 37 mm |
| Width | 120 mm |
| Depth | Length | 165 mm |
| Warranty | 2 Years |
| Connector Type | Bare wire |
| Input Voltage | 9 - 32V |
| Output Voltage | 12V DC |
| Max. Charging Voltage | 15.3V |
| Max. Rated Output Current | 25A |
| Nominal Output Power | 375W |
| Input Fuse Rating | 40A |
| Output Fuse Rating | 60A |
REDARC BCDC CORE40 DC BATTERY CHARGER
REDARC's BCDC Core 40A DC to DC In-Cabin Battery Charger is the next evolution of the legendary BCDC platform that has been powering off-grid adventures for over 10 years.
The BCDC Core is the perfect DC to DC charging solution for in-cabin, canopy, or battery box setups where dust and weatherproofing isn’t required. Each BCDC Core features REDARC’s tried and tested dual input DC charging tech plus an MPPT solar regulator and Green Power Priority™ all in the familiar and compact BCDC form factor. These features allow the BCDC Core to efficiently charge from both the alternator and solar simultaneously, ensuring maximum charge capacity no matter the situation.
Max Charge Efficiency
The BCDC Core features a Maximum Power Point Tracking (MPPT) solar regulator and 'Green Power Priority™'. With these features the BCDC Core will charge from both solar and the alternator simultaneously, maximising its charge rate and minimising the load on your alternator, saving fuel.
Compact & Silent
With no loud fans or relays and a small form factor, the BCDC Core can be tucked away, leaving room in the cabin for more important things. Don't ruin the look of your interior with bulky electronics. Hide it under the rear floor, behind a side panel or under the seats and make your power set up look like it was meant to be there.
Lithium Ready
With chemistry specific charging profiles, including lithium the BCDC Core ensures your batteries are ready for your next adventure. The award-winning technology in the BCDC Core has been independently verified and tested to ensure battery life is maximised, charging your battery to a proven 100%.*
As a guide the BCDC Core 40A is typically used for lead acid battery banks over 200Ah and lithium batteries over 100Ah. Check the manufacturer’s data for your battery and ensure that the ‘Continuous Current Rating’ of the charger does not exceed the manufacturer’s recommended maximum charging current. For smaller batteries, REDARC recommends the BCDC Core 25A.
*Large capacity battery banks may require a few cycles to fully charge.
Backed by the Best
The BCDC Core is designed, tested and manufactured in Australia and is backed by our leading technical support and national REDNetwork certified installer network.
If you’re heading out into the bush and want to get there and back again safely – you can trust REDARC.
| Specifications |
| Battery Chemistry | Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only |
| Continuous Rating | 40A |
| Power Type - AC DC | DC TO DC |
| No Load Current | <100mA |
| Solar Input Voltage | 9 - 32V |
| Solar Switch On Voltage | 9V |
| Standby Current | <8mA |
| Operating Temperature | -15°C to 80°C |
| Weight | 900g |
| Height | 37 mm |
| Width | 120 mm |
| Depth | Length | 165 mm |
| Warranty | 2 Years |
| Connector Type | Bare wire |
| Input Voltage | 9 - 32V |
| Output Voltage | 12V DC |
| Max. Charging Voltage | 15.3V |
| Max. Rated Output Current | 40A |
| Nominal Output Power | 600W |
| Input Fuse Rating | 60A |
| Output Fuse Rating | 60A |
REDARC BCDC ALPHA25 DC BATTERY CHARGER
With a combination of DC and solar charging, the BCDC Alpha25 is a rugged 12V, 25A DC-DC battery charger perfect for charging batteries used in a range of recreational vehicles and 4x4s so you can adventure for longer.
Always charged, never stranded, stay powered up wherever your adventure takes you with REDARC’s BCDC Alpha25. Featuring 25A of advanced charging technology, this DC to DC charger keeps your start and secondary batteries charged using power from your vehicle’s alternator or solar. The BCDC Alpha's built in Green Power Priority™ will prioritise solar input, minimising the load on your alternator and saving fuel.
INSTANT INSIGHT
Stay informed and monitor the BCDC Alpha’s charge status in real-time through Bluetooth and the RedVision smartphone app. Gain full control of your power with configurable input current limits, allowing you to customise it to your system requirements and protect your electrical system.
START BATTERY CHARGING
Recover a flat start battery with the push of a button in as little as 15 minutes, giving you the power to safely start your vehicle and get you back on the road in no time. Don’t let excess solar power go to waste, utilise solar to automatically top up the start battery when the secondary battery is full.
SIMPLIFIED INSTALL
The BCDC Alpha’s pushbutton interface and screw connections allow for a simple installation. There’s no solder or tricky wiring configurations and, with a range of wiring kits and mounting brackets available, installation is a breeze.
BUILT TOUGH
Outlast and outperform other chargers. Designed, tested and manufactured in Australia, the BCDC Alpha25 has IP67/69K dust and moisture protection making it the most reliable, highest performing dual battery charger available.
FEATURES
- 25A Charging from DC and solar power
- Compatible with all common automotive battery types including lithium (LiFePO4)
- Outlast other chargers with IP67/69K dust and moisture protection
- Easy installation with pushbutton interface and screw connections
- Charge back to your start battery with excess solar
- Recover a flat start battery with the push of a button
- Remote monitoring and control from the RedVision app with Bluetooth
- Protect your vehicle’s alternator with adjustable input current limit
- Future proof charging with over-the-air updates
| Specifications |
| Compatible Battery Types | AGM, Gel, Calcium, Standard Lead Acid, Heated Lithium, Standard Lithium |
| Start Battery Input Voltage Range | 9 - 32VDC |
| Solar Input Voltage Range | 9 - 48VDC |
| Nominal Output Voltage | 12V |
| Nominal Current Rating | 25A |
| Operating Temperature | –40°C to 85°C |
| Weight | 925g |
| Height | 44 mm |
| Width | 164 mm |
| Depth | Length | 146 mm |
| Warranty | 2 Years |
REDARC BCDC ALPHA50 DC BATTERY CHARGER
Perfect for charging batteries in a range of recreational vehicles, REDARC’s BCDC Alpha50 is a rugged 12V, 50A DC to DC battery charger, ensuring you’re always charged and never stranded.
Stay powered up wherever your adventure takes you with REDARC’s BCDC Alpha 50A. Featuring 50A of advanced charging technology, this DC to DC charger keeps your start and secondary batteries charged using power from your vehicle’s alternator or solar. The BCDC Alpha's built in Green Power Priority™ will prioritise solar input, minimising the load on your alternator and saving fuel.
INSTANT INSIGHT
Stay informed and monitor the BCDC Alpha’s charge status in real-time through Bluetooth and the RedVision smartphone app. Gain full control of your power with configurable input current limits, allowing you to customise it to your system requirements and protect your electrical system.
START BATTERY CHARGING
Recover a flat start battery with the push of a button in as little as 15 minutes, giving you the power to safely start your vehicle and get you back on the road in no time. Don’t let excess solar power go to waste, utilise solar to automatically top up the start battery when the secondary battery is full.
SIMPLIFIED INSTALL
The BCDC Alpha’s pushbutton interface and screw connections allow for a simple installation. There’s no solder or tricky wiring configurations and, with a range of wiring kits and mounting brackets available, installation is a breeze.
BUILT TOUGH
Outlast and outperform other chargers. Designed, tested and manufactured in Australia, the BCDC Alpha50 has IP67/69K dust and moisture protection making it the most reliable, highest performing dual battery charger available.
FEATURES
- 50A Charging from DC and solar power
- Compatible with all common automotive battery types including lithium (LiFePO4)
- Outlast other chargers with IP67/69K dust and moisture protection
- Easy installation with pushbutton interface and screw connections
- Charge back to your start battery with excess solar
- Recover a flat start battery with the push of a button
- Remote monitoring and control from the RedVision app with Bluetooth
- Protect your vehicle’s alternator with adjustable input current limit
- Future proof charging with over-the-air updates
| Specifications |
| Compatible Battery Types | AGM, Gel, Calcium, Standard Lead Acid, Heated Lithium, Standard Lithium |
| Start Battery Input Voltage Range | 9 - 32VDC |
| Solar Input Voltage Range | 9 - 48VDC |
| Nominal Output Voltage | 12V |
| Nominal Current Rating | 50A |
| Operating Temperature | –40°C to 85°C |
| Weight | 960g |
| Height | 44 mm |
| Width | 164 mm |
| Depth | Length | 146 mm |
| Warranty | 2 Years |
