Remote on/off terminal The remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or by for example the engine run/stop switch (see manual).
All models are short circuit proof and can be paralleled to increase output current An unlimited number of units can be connected in parallel.
High temperature protected The output current will reduce at high ambient temperature.
IP43 protection When installed with the screw terminals oriented downwards.
Screw terminals No special tools needed for installation.
Input fuse (not replaceable) On 12 V and 24 V input models only.
Adjustable output voltage Not intended for battery charging. Please consider using an Orion-Tr Smart for battery charging.
SPECIFICATIONS
Input voltage range
16-35 V
Under voltage shut down
14V
Under voltage restart
15V
Nominal output voltage
48.2 V
Output voltage adjust range
40-60 V
Output voltage tolerance
+/- 0,2 V
Output noise
2 mV rms
Cont. output current at nominal output voltage and 40 °C
6A
Maximum output current (10 s) at nominal output voltage
