VICTRON ENERGY

ORION-TR 24V TO 12V-20A (240W) DC-DC CONVERTER

Name: ORION-TR 24V TO 12V-20A (240W) DC-DC CONVERTER
Brand: VICTRON ENERGY
SKU: ORI241220200
Price: 65.00 AUD
Availability: InStock

SKU:ORI241220200

$65.00

Sale Sold out

Taxes included. Shipping calculated at checkout.

MANUALS & APPS

Orion-Tr DC-DC Isolated Converters Datasheet

Orion-Tr DC-DC Isolated Converters Manual

VictronConnect App For IOS

VictronConnect App For Android

High efficiency

Using synchronous rectification, full load efficiency exceeds 95%.

IP43 protection

When installed with the screw terminals oriented downwards.

Screw terminals

No special tools needed for installation.

Input voltage range	18-35V
Output voltage	12.5V
Efficiency	97%
Continuous output current	20A
Max. Output current	25A
Galvanic isolation	NO
Off load current	< 35mA
Operating temperature range	-20 to +55°C
DC connection	Screw terminals
Maximum cable cross-section	6 mm² AWG10
Weight	0,25 kg
Dimensions HxWxD	73x94x45 mm
