Aluminium Enclosure 560Ah LiFePO4 Battery | 380A BMS

🔋 CUSTOM LITHIUM ALUMINIUM ENCLOSURE CARAVAN & RV 560AH LiFePO4 BATTERY – AUSTRALIAN MADE

560Ah • 12.8V LiFePO4 • 380A Continuous Discharge • 130A Recommended Charge • 47.4kg • 7 Year Warranty

The Custom Lithium Aluminium Enclosure Caravan & RV 560Ah Battery is designed for serious off-grid electrical systems requiring substantial energy storage, high-current capability and reliable performance for extended touring.

With 560Ah of lithium capacity, it is suited to caravans, motorhomes, 4WDs and off-grid installations running refrigeration, Starlink, induction cooking, coffee machines, washing machines and appropriately engineered air-conditioning and inverter systems.

Built in Brisbane using premium A-grade automotive LiFePO4 cells, the battery combines a modified Heltech BMS, active cell balancing and the manufacturer's stated high-strength ABS & aluminium enclosure with a 380A continuous discharge capability.

---

⭐ KEY FEATURES

🔋 Massive 560Ah LiFePO4 Capacity
Provides substantial stored energy for extended off-grid travel and high-demand caravan or motorhome electrical systems.

⚡ 380A Continuous Discharge
High-current capability supports demanding 12V equipment and appropriately designed high-power inverter installations.

🇦🇺 Australian Made
Built in Brisbane and supplied as a certified Australian Made product.

🧠 Modified Heltech BMS
The integrated battery management system helps protect against overheating, over-discharge and low-temperature charging conditions.

⚖️ Active Cell Balancing
The active balancer helps manage individual cells and maintain consistent battery performance.

🔋 A-Grade Automotive LiFePO4 Cells
Manufactured using premium lithium iron phosphate cells for demanding caravan, RV and off-grid applications.

🛡️ High-Strength Enclosure
The supplied product information describes a high-strength ABS & aluminium enclosure designed to protect the internal cells and components while maintaining a compact installation footprint.

🚙 Built for Touring & Corrugations
Internal components are insulated against vibration to help protect the battery during rough-road and remote-area travel.

🧪 Individually Bench Tested
Each battery is individually bench tested before supply as part of Custom Lithium's quality-control process.

🛡️ 7 Year Warranty
Backed by a full 7-year manufacturer warranty.

---

🚐 HIGH-CAPACITY POWER FOR EXTENDED OFF-GRID TOURING

The 560Ah Caravan & RV battery is designed for electrical systems with substantial daily energy demands and customers wanting to spend extended periods away from powered sites.

It can support compatible equipment including:

• ❄️ 12V fridges & freezers
• ❄️ Air conditioning through a suitably engineered inverter system
• 📡 Starlink
• 🍳 Induction cooking
• ☕ Coffee machines
• 🧺 Washing machines
• 💨 Air compressors
• 🛠️ Tools & battery chargers
• 💡 Caravan & camp lighting
• 🔌 Compatible 240V appliances through an appropriately sized inverter

⚠️ High-power 240V appliances require an appropriately sized inverter together with correctly engineered DC cabling, fusing, isolation and battery protection. Actual appliance suitability and runtime depend on power consumption, surge demand, inverter efficiency and the complete electrical system.

---

🔋 PREMIUM LiFePO4 CELL TECHNOLOGY

The battery is constructed using A-grade automotive LiFePO4 cells, combined with a high-current BMS and active cell balancing.

The supplied product information positions LiFePO4 as a suitable battery chemistry for demanding caravan, RV and off-grid applications where safety, reliability and high-current performance are important.

---

📊 TECHNICAL SPECIFICATIONS

Capacity: 560Ah

Nominal Voltage: 12.8V

Continuous Discharge: 380A

Peak Discharge / Protection: 1200–1600A as specified by manufacturer

Recommended Charge Current: 130A

Charge Voltage: 14.2–14.6V

Absorption / Float Voltage: 13.4–13.6V

Low-Voltage Cut-Off: 10.5V

Operating Temperature: 0°C to 65°C

Terminals: M10

Battery Body Dimensions: 425 × 340 × 262mm as supplied

Overall Dimensions: 465mm L × 335mm W × 262mm H as supplied

Weight: Approx. 47.4kg

Battery Chemistry: LiFePO4

BMS: Modified Heltech High-Current BMS

Cell Balancing: Active Balancer

Enclosure: High-Strength ABS & Aluminium as specified by manufacturer

Warranty: 7 Years

Manufactured: Brisbane, Australia

⚠️ The supplied specification describes “1200A–1600A Protection”. Because the duration and exact BMS trip behaviour are not provided, this figure should not be interpreted as a continuous discharge rating or guaranteed cranking-current figure.

⚠️ The manufacturer states that the BMS incorporates low-temperature cut-off protection, however the exact cut-off and reset temperatures have not been supplied.

---

⚡ HIGH-CURRENT PERFORMANCE

The stated 380A continuous discharge capability provides substantial current availability for high-demand caravan and motorhome electrical systems.

This makes the battery suitable for appropriately engineered high-power inverter installations, but inverter selection must still account for actual DC current demand, surge requirements, battery state of charge, cable sizing, fuse protection, connection quality and BMS limits.

---

🔌 CHARGING REQUIREMENTS

The supplied specifications recommend a charge current of up to 130A.

• Bulk / Charge Voltage: 14.2–14.6V
• Absorption / Float Voltage: 13.4–13.6V

Compatible lower-output charging systems can also be used, although recharge times will increase substantially with a 560Ah battery.

Your DC-DC charger, solar charge controller and 240V charger should all be configured to suit the required LiFePO4 charging profile.

---

📐 HIGH CAPACITY IN A COMPACT PACKAGE

The supplied overall dimensions are 465mm L × 335mm W × 262mm H, providing 560Ah of lithium storage in a package designed for caravan, motorhome and off-grid installations where available battery space remains valuable.

⚠️ The supplied body dimensions are listed as 425 × 340 × 262mm, while the overall dimensions are listed as 465 × 335 × 262mm. Because the stated body width exceeds the overall width, these measurements should be confirmed before planning a tight installation.

⚠️ Dimensions shown in manufacturer images are indicative only. Physically confirm the battery and available installation space before fitting.

---

🇦🇺 AUSTRALIAN MADE

Custom Lithium states that its Caravan & RV batteries are Australian Made and built in Brisbane.

Each battery is individually bench tested before supply and backed by a 7-year manufacturer warranty.

---

🛠️ PROFESSIONAL INSTALLATION RECOMMENDED

With 560Ah of capacity and a 380A continuous discharge rating, correct electrical system design is particularly important.

⚠️ Custom Lithium recommends installation by a qualified auto electrician. Correct cable sizing, fuse protection, isolation, mounting and charging configuration are essential for safe and reliable operation.

---

❓ QUICK FAQ

Can I replace an AGM battery bank with this 560Ah lithium battery?

Potentially, but the complete charging system must be lithium compatible. Check your DC-DC charger, solar charge controller, 240V charger and other connected equipment before changing from AGM to LiFePO4.

What charging profile does it require?

The supplied specifications call for a 14.2–14.6V charge voltage and 13.4–13.6V absorption/float voltage.

What charge current is recommended?

The stated recommended charge current is 130A. Lower-output compatible chargers can also be used, but a 560Ah battery will take considerably longer to recharge.

Can it run air conditioning, induction cooking or a washing machine?

It can be used as part of an appropriately engineered inverter system supplying high-demand appliances. Actual suitability and runtime depend on appliance wattage, inverter efficiency, surge demand and the complete electrical system.

Can the 560Ah battery run a large inverter?

The stated 380A continuous discharge capability provides substantial current availability. Suitable inverter size still depends on actual DC current demand, surge requirements, cable sizing, fuse protection and BMS limits.

---

🔋 560AH OF AUSTRALIAN-MADE OFF-GRID POWER

With 560Ah of lithium capacity, 380A continuous discharge capability, active balancing, a modified Heltech BMS and Australian manufacture, this Custom Lithium Caravan & RV battery is designed for demanding touring and extended off-grid electrical systems.

Serious capacity. High-current performance. Built for extended Australian touring.
