Aluminium Enclosure - Caravan & RV 400Ah LiFePO4 Battery | 380A BMS

🔋 CUSTOM LITHIUM ALUMINIUM ENCLOSURE CARAVAN & RV 400AH LiFePO4 BATTERY – AUSTRALIAN MADE

400Ah • 12.8V LiFePO4 • 380A Continuous Discharge • 130A Recommended Charge • 41.7kg • 7 Year Warranty

The Custom Lithium Aluminium Enclosure Caravan & RV 400Ah Battery is designed for high-demand off-grid systems requiring substantial capacity, high-current performance and a durable enclosure for caravan, motorhome and 4WD installations.

With 400Ah of lithium capacity, it can form the foundation of a system powering refrigeration, Starlink, induction cooking, coffee machines, washing machines and appropriately designed air-conditioning and inverter systems.

Built in Brisbane using premium A-grade automotive LiFePO4 cells, it combines a modified Heltech BMS, active cell balancing and the manufacturer's stated high-strength ABS & aluminium enclosure with a 380A continuous discharge capability.

---

⭐ KEY FEATURES

🔋 400Ah LiFePO4 Capacity
Substantial energy storage for larger caravan, motorhome and off-grid electrical systems.

⚡ 380A Continuous Discharge
High-current capability supports demanding 12V loads and appropriately engineered high-power inverter installations.

🇦🇺 Australian Made
Built in Brisbane and supplied as a certified Australian Made product.

🧠 Modified Heltech BMS
The integrated battery management system helps protect against overheating, over-discharge and low-temperature charging conditions.

⚖️ Active Cell Balancing
The active balancer helps manage individual cells and maintain consistent battery performance.

🔋 Premium A-Grade Automotive Cells
Manufactured using A-grade automotive LiFePO4 cells for demanding auxiliary and off-grid applications.

🛡️ High-Strength Enclosure
The supplied product information describes a high-strength ABS & aluminium enclosure designed to reduce footprint and protect the internal cells and components.

🚙 Built for Touring & Corrugations
Internal components are insulated against vibration to help protect the battery during rough-road and remote-area travel.

🧪 Individually Bench Tested
Each battery is individually bench tested before supply as part of Custom Lithium's quality-control process.

🛡️ 7 Year Warranty
Backed by a full 7-year manufacturer warranty.

---

🚐 BUILT FOR HIGH-DEMAND CARAVAN & RV SYSTEMS

The 400Ah Caravan & RV battery is suited to electrical systems designed to spend extended periods away from powered sites while continuing to run substantial electrical loads.

It can support compatible equipment including:

• ❄️ 12V fridges & freezers
• ❄️ Air conditioning through a suitably engineered inverter system
• 📡 Starlink
• 🍳 Induction cooking
• ☕ Coffee machines
• 🧺 Washing machines
• 💨 Air compressors
• 🛠️ Tools & battery chargers
• 💡 Caravan & camp lighting
• 🔌 Compatible 240V appliances through an appropriately sized inverter

---

🔋 PREMIUM LiFePO4 CELL TECHNOLOGY

The battery is built using A-grade automotive LiFePO4 cells, combined with a high-current BMS and active cell balancing.

The supplied product information positions LiFePO4 as a suitable chemistry for demanding caravan, RV and off-grid environments where safety, reliability and high-current capability are important.

---

📊 TECHNICAL SPECIFICATIONS

Capacity: 400Ah

Nominal Voltage: 12.8V

Continuous Discharge: 380A

Peak Discharge / Protection: 1200–1600A as specified by manufacturer

Recommended Charge Current: 130A

Charge Voltage: 14.2–14.6V

Absorption / Float Voltage: 13.4–13.6V

Low-Voltage Cut-Off: 10.5V

Operating Temperature: 0°C to 65°C

Terminals: M10

Battery Body Dimensions: 425 × 265 × 262mm

Overall Dimensions: 465mm L × 265mm W × 262mm H

Weight: Approx. 41.7kg

Battery Chemistry: LiFePO4

BMS: Modified Heltech High-Current BMS

Cell Balancing: Active Balancer

Enclosure: High-Strength ABS & Aluminium as specified by manufacturer

Warranty: 7 Years

Manufactured: Brisbane, Australia

---

⚡ HIGH-CURRENT PERFORMANCE

The stated 380A continuous discharge capability provides substantial current availability for high-demand caravan and motorhome electrical systems.

This makes the battery suitable for appropriately engineered high-power inverter installations, but inverter selection still needs to account for DC current demand, surge requirements, battery state of charge, cable sizing, fusing, connection quality and BMS limits.

---

🔌 CHARGING REQUIREMENTS

The supplied specifications recommend a charge current of up to 130A.

• Bulk / Charge Voltage: 14.2–14.6V
• Absorption / Float Voltage: 13.4–13.6V

Compatible lower-output charging systems can also be used, although recharge times will increase with a 400Ah battery.

Your DC-DC charger, solar charge controller and 240V charger should all be configured to suit the required LiFePO4 charging profile.

---

📐 COMPACT HIGH-CAPACITY DESIGN

The battery body measures approximately 425 × 265 × 262mm, with stated overall dimensions of 465mm L × 265mm W × 262mm H.

This provides substantial 400Ah capacity in a footprint designed for caravan, motorhome, 4WD and off-grid installations where available battery space is valuable.

---

🇦🇺 AUSTRALIAN MADE

Custom Lithium states that its Caravan & RV batteries are Australian Made and built in Brisbane.

Each battery is individually bench tested before supply and backed by a 7-year manufacturer warranty.

---

🛠️ PROFESSIONAL INSTALLATION RECOMMENDED

With 400Ah of capacity and a 380A continuous discharge rating, correct system design and installation are particularly important.

⚠️ Custom Lithium recommends installation by a qualified auto electrician. Correct cable sizing, fuse protection, isolation, mounting and charging configuration are essential for safe and reliable operation.

---

❓ QUICK FAQ

Can I replace an AGM battery bank with this 400Ah lithium battery?

Potentially, but your complete charging system must be lithium compatible. Check your DC-DC charger, solar controller, 240V charger and other connected equipment before changing from AGM to LiFePO4.

What charging profile does it require?

The supplied specifications call for a 14.2–14.6V charge voltage and 13.4–13.6V absorption/float voltage.

What charge current is recommended?

The stated recommended charge current is 130A. Lower-output compatible chargers can also be used, but will take longer to recharge the 400Ah battery.

Can it run air conditioning, induction cooking or a washing machine?

It can be used as part of an appropriately engineered inverter system supplying high-demand appliances. Actual suitability and runtime depend on appliance wattage, inverter efficiency, surge demand and the complete electrical system.

Can it run a large inverter?

The stated 380A continuous discharge capability provides substantial current availability. Suitable inverter size still depends on actual DC current, surge demand, cable sizing, fuse protection and BMS limits.

---

🔋 400AH OF AUSTRALIAN-MADE OFF-GRID POWER

With 400Ah of lithium capacity, 380A continuous discharge capability, active balancing, a modified Heltech BMS and a durable enclosure, this Custom Lithium Caravan & RV battery is designed for high-demand touring and off-grid electrical systems.

High capacity. High-current capability. Built for serious Australian touring.
