REDARC

160W MONOCRYSTALLINE SOLAR BLANKET

160W MONOCRYSTALLINE SOLAR BLANKET

SKU:SMFB1160

Regular price $850.00
Regular price Sale price $850.00
Sale Sold out

Tax included. Shipping calculated at checkout.

160W Monocrystalline Folding Solar Blanket by REDARC that is lightweight and rugged, while portable and compact to move between car and campsite. A perfect addition to your BCDC Battery Charger or Manager30, both of which have internal solar MPPT regulators as standard.

SOLAR BLANKET FOR 4WD AND CARAVAN TRAVEL

With genuine industry standard Anderson™ SB™50 connectors, setting up camp is easier than ever. These high-quality Anderson™ plugs are simple and fast to connect with no screw terminals and no risk of poor connections from frayed wires or loose terminals – just plug and play!

REDARC 160W MONOCRYSTALLINE SOLAR BLANKET FEATURES

  • Designed for portability and strength with efficient monocrystalline cells
  • Lightweight and highly portable
  • The lightest REDARC solar option
  • Anti-reflective scratch resistant with ETFE coating
  • Genuine Industry Standard Anderson™ SB™50 plug connection
  • Designed for 12V Automotive, Marine and Recreational Vehicle battery systems
  • High power output
SOLAR CELL TYPE  Monocrystalline
OPEN CIRCUIT VOLTAGE 21.5V
WATTS 160W
MATERIAL Canvas
MAX. POWER VOLTAGE 18V
STANDBY CURRENT <10mA (12V) / <4.5mA (24V)
SHORT CIRCUIT CURRENT 9.5A
OPERATING TEMPERATURE 0°C to +85°C
CABLE LENGTH 120 mm
WEIGHT 4.8 kg
HEIGHT 1.2 mm
WIDTH 740 mm
LENGTH 1635 mm
WARRANTY 2 Years
DIMENSIONS OPEN 1635 x 740 x 2.5 mm
DIMENSIONS CLOSED 365 x 365 x 50 mm
POWER TOLERANCE ± 5%
MAX POWER CURRENT 8.9A
CONNECTOR TYPE Anderson™ SB™ 50
PEAK POWER 160W
